W H A T ’S O N T H E M O D U L E ?
Edge connector, P3 ConnectCore 9C and Wi-9C
Dimm
Pin
Signal
BootStrap
(BS) /
System /
Other
UART
SPI
I2C
USB
LCD
IEEE
1284
PWM /
Timer
/ IRQ
Notes
108
LNK_LED
Ethernet
Remote if no Ether net connector on
Module
109
GPIO[16]
OVRH#
PFAULT#
PWM0
OVRH#: USB overcurrent input.
Available as GPIO on modules with
USB hub or Ethernet only. Not
available as GPIO if an external Host
USB port is implemented using
DM1 and DP1.
PFAULT#: Primary on GPIO[06]
PWM0: Duplicate on GPIO[10]
110
ADDRESS_6
Address bus
CSO parallel port
111
GPIO[17]
ND4
PONH#
PONH#: USB power on output.
Available as GPIO on modules with
USB hub or Ethernet only. Not
available as GPIO if an external Host
USB port is implemented using
DM1 and DP1.
112
113
ADDRESS_7
OVR3#
Address bus
CSO parallel port
USB port 3 overcurrent
Remote if Hub on module
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
OVR4#
PON3#
PON4#
OVR1#
OVR2#
PON1#
PON2#
GND
GND
DM4
DP4
GND
GND
DM3
DP3
GND
GND
USB port 4 overcurrent
Remote if Hub on module
USB port 3 power-on
Remote if Hub on module
USB port 4 power-on
Remote if Hub on module
USB port 1 overcurrent
Reserved for future use; no connect
USB port 2 overcurrent
Reserved for future use; no connect
USB port 1 power-on
Reserved for future use; no connect
USB port 2 power-on
Reserved for future use; no connect
Common GND return
Common GND return
USB port 4 data (-)
Remote if Hub on module
USB port 4 data (+)
Remote if Hub on modulet
Common GND return
Common GND return
USB port 3 data (-)
Remote if Hub on module
USB port 3 data (+)
Remote if Hub on module
Common GND return
Common GND return
www.digiembedded.com
23
